Regularly inspect for wear, ensure proper alignment, and clean the valve to prevent residue buildup; PTFE’s non-stick nature helps reduce frequent maintenance needs.
Mac PTFE Lining, located in Texas, United State, manufactures a full line of high-quality PTFE Lined Butterfly Valves that are known for their durability, strength, and chemical-resistant properties. Mac PTFE Solutions manufactures and specializes in corrosion-resistant valve solutions for the chemical processing, pharmaceuticals, and petrochemical industries. Mac PTFE’s PTFE Lined Butterfly Valves provide reliable leak-proof service in aggressive-flow service and have the potential for service life nearly anywhere in the industrial marketplace while maximizing the efficiency of maintenance. Mac PTFE Solutions manufactures PTFE Lined Butterfly Valves to engineered precision specifications for industry-leading smooth operation, tight sealing, and protection for exceptional environments that demand safety and efficiency.
PTFE Lined Butterfly Valve is a type of valve that has a disc that turns to allow or stop the flow of fluid, with PTFE (Polytetrafluoroethylene) lining inside the valve body and in the valve disc. The lining offers great chemical resistance, making it good for use within industrial processes and piping systems using very aggressive and corrosive fluids like many chemical and pharmaceutical processes. The PTFE lining allows for smoother operation by reducing friction reducing operating temperatures and allowing for a better seal leak proof to minimize leaks and improve durability by protecting the metal parts from corrosion and allowing the wear and for reliable and long-lasting repetitive use in harsh environments.
| Seal Material | PTFE/ PFA |
|---|---|
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
Mac PTFE Lining is a leading supplier of PTFE Lined Butterfly Valve in Texas, United State, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| SIZE | F/F†(±2) (mm) | A (mm) | B (mm) | L (mm) | Min. PipeØ* (mm) | C$ (mm) | Torque§(N.m) |
| DN40-1 1/2” | 33 | 90 | 65 | 260 | 26 | 1.5 | 15 |
| DN50-2” | 43 | 100 | 67 | 260 | 29 | 1.5 | 30 |
| DN65-2 1/2” | 46 | 115 | 65 | 260 | 49 | 1.5 | 40 |
| DN80-3” | 46 | 120 | 80 | 260 | 68 | 1.5 | 40 |
| DN100-4” | 52 | 158 | 95 | 260 | 88 | 1.5 | 50 |
| DN150-6” | 58♦ | 190 | 120 | 325 | 145 | 1.5 | 100 |
| DN200-8” | 64♦ | 220 | 162 | G.Box | 196 | 3 | 180 |
| DN250-10” | 70♦ | 250 | 200 | G.Box | 245 | 3 | 250 |
| DN300-12” | 80♦ | 270 | 232 | G.Box | 293 | 3 | 350 |
| DN350-14” | 92 | 300 | 255 | G.Box | 332 | 3 | 500 |
| DN400-16” | 102 | 300 | 290 | G.Box | 378 | 3 | 600 |
| DN450-18” | 114 | 395 | 310 | G.Box | 430 | 3 | 1200 |
| DN500-20” | 127 | 420 | 342 | G.Box | 480 | 3 | 1500 |
| DN600-24” | 156♦ | 510 | 400 | G.Box | 572 | 6 | 2000 |
The PTFE lining protects against harsh chemicals, making the valve ideal for corrosive applications.
The low-friction PTFE surface ensures easy, efficient valve movement with minimal wear.
Performs reliably in extreme temperatures, both hot and cold, without deformation or damage.
Requires minimal upkeep due to its durable, self-lubricating PTFE lining, reducing downtime and costs.
PTFE lining provides excellent chemical resistance, non-stick properties, and durability, making it ideal for handling corrosive or reactive fluids in demanding industrial applications.
Yes, they typically operate efficiently up to 200°C, depending on design, making them suitable for a wide range of thermal and chemical process environments.
A PTFE lined butterfly valve is a flow control device featuring a disc that rotates and a PTFE lining that resists corrosion in aggressive chemical environments.
Regularly inspect for wear, ensure proper alignment, and clean the valve to prevent residue buildup; PTFE’s non-stick nature helps reduce frequent maintenance needs.
They’re used in industries like chemical processing, pharmaceuticals, and water treatment where corrosion resistance and non-contaminating flow are essential for safe and efficient operation.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Texas, United State.
