Mac PTFE Lining, located in Texas, is a leading manufacturer of top-notch PTFE Lined Elbows, serving industries that require outstanding corrosion resistance and durability. we focus on creating elbows that facilitate seamless fluid handling, making their products essential in sectors like chemical processing, pharmaceuticals, petrochemicals, and water treatment. The PTFE-lined elbows from Mac PTFE Lining offer remarkable chemical resistance, smooth flow and long-lasting reliability, even in tough operating conditions. With a strong dedication to quality and innovation, the company provides customized solutions that align with industry standards, ensuring efficient performance and operational excellence for clients around the globe.
A PTFE Lined Elbow is a specialized pipe fitting that features an internal coating of Polytetrafluoroethylene (PTFE), which offers outstanding resistance to chemicals and protects against corrosion. It’s specifically designed to redirect fluid flow usually at angles of 90 or 45 degrees, within piping systems. Thanks to the PTFE lining, this fitting stands up to harsh chemicals, high temperatures and wear and tear, making it a perfect choice for sectors like chemical processing, pharmaceuticals and petrochemicals. This fitting beautifully merges the robust strength of metal with the non-reactive qualities of PTFE, ensuring dependable and long-lasting performance.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : PFA
Mac PTFE Lining is a leading supplier of PTFE Lined Elbow in Texas, United State, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
|
NB
|
ID
|
RF
|
OD
|
PCD
|
No.Of Holes x Dia Of Holes
|
Lining Thickness Standard
|
Lining Thickness Full Vacuum
|
Length Max.
|
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Ensures secure and safe flow direction
Performs reliably in elevated heat conditions.
Minimizes turbulence and pressure drop
Handles aggressive chemicals without degradation.
PTFE lined elbows are available in standard and custom sizes ranging from 1” to 12” or more.
Yes, we provide custom sizes, angles, and lining thickness based on your system design and performance needs.
Yes, they can withstand temperatures up to 230°C, depending on the pressure and application requirements.
It redirects flow in corrosive systems while resisting chemicals, pressure, and temperature variations.
Yes, they are non-toxic, hygienic, and ideal for food, beverage, and pharmaceutical applications.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Texas, United State.
